High Efficiency LED Tri-proof Light-B Series

Adopted 95% transmittance PC cover to ensure soft and uniform light, provide good visual effects. The used of high quality LED chip to make the light stable and bright. The inside aluminum heat sink makes good heat dissipation, ensuring the LED chip maintain a low temperature while working for a long time, extending the service life of the lamp.

High Efficiency LED Tri-proof Light-B Series

Adopted 95% transmittance PC cover to ensure soft and uniform light, provide good visual effects. The used of high quality LED chip to make the light stable and bright. The inside aluminum heat sink makes good heat dissipation, ensuring the LED chip maintain a low temperature while working for a long time, extending the service life of the lamp.

Product Feature

  • Top Quality 94V0 Fireproof PC Housing, IK10
  • Rated, Super High Toughness, Strength & Elasticity
  • High Light Transmittance PC Cover, Milky & Semi-Clear & Transparent Options
  • IP65, Waterproof, Dustproof, Anti-corrosion
  • Playand Plug Design, Quick Installation, Easy to Power & Link
  • Ultra  High Lumen Efficiency up to 160lm/W for Finished Lamp, 200lm/Wfor LED
  • Double Heat Dissipation: Extruded 6063 Aluminum Board +  Wide Aluminum PCB
  • Option: Zigbee, Emergency,Motion Sensor

Product Specification

Model NO.

HS-TPL- A60 HS-TPL- A120 HS-TPL-A150

Actual Size

600*83*68MM 1200*83*68MM 1200*83*68MM

Power

20W 40W 60W

Luminous(lm)

3000LM 6000LM 9000LM

Color Temperature

3000K/ 4000K/ 5000K/ 6000K/ CCT Switchable
Lumen Efficiency

150LM/W

CRI

80-85Ra

Power Factor

>0.9

Input Voltage

AC200-240V, 50/60Hz

IP Rate

IP65

Working Temperature

-20-50℃

Main Material

Aluminum Housing+PC Cover

Frame Color

Silver
Warranty

5 Years

Certification

CE, RoHS

Remarks : HS-TPL-A 60-CCT HS-TPL-A120-CCT HS-TPL-A150-CCT HS-TPL-A60-MS HS-TPL-A120-MS HS-TPL-A150-MS

HS-TPL-A60-EM HS-TPL-A120-EM HS-TPL-A150-EM

HS-TPL-A60-MSEM HS-TPL-A120-MSEM HS-TPL-A150-MSEM

CCT:Zigbee CCT Changeable

MS: Motion Sensor

EM:Emergency Module

MSEM:Motion Sensor+Emergency

Product Parameter

Model NO.

Length Power Luminous(LM) Lumen Efficiency Carton Size(mm) QTY/CTN(PCS) G.W./CTN(KG)

HS-TPL- B60

2 18W 2800 160LM/W 680x270x260 12 11kg

HS-TPL- B120

4 35W 5600 160LM/W 1280x270x260 12

21kg

HS-TPL- B135 4.2 35W 5600 160LM/W 1580x270x260 12

26kg

HS-TPL- B150 5 45W 7200 160LM/W 1580x270x260 12

26kg
